A Modern Look at Van Riper's Phonetic Placement Approach

Posted by Deborah Grauzam on

by Robyn Merkel-Walsh, MA, CCC-SLP

This poster was presented at the 2016 annual ASHA Connect Convention, Poster Session #PS02.

Download the poster here

ABSTRACT

Presentation explores 1) traditional versus phonological therapy, 2) the sensory-motor system as it relates to speech, 3) the importance of tactile and proprioception in articulation therapy, 4) shaping placement of the articulators to improve speech clarity.

LEARNER OUTCOMES

1. Participants will be able to differentiate phonological versus traditional articulation therapy.

2. Participants will be able to define the three stages of Van Riper’s Phonetic Placement Approach.

3. Participants will be able to use at least three oral placement cues in order to facilitate speech movements.

DISCUSSION

Two widely used models of articulation therapy include the traditional and phonological models (Bowen, 2005). While studies suggest that the phonological model may prove more positive results than the traditional model (Klein, 1996), Van Riper’s Phonetic Placement Approach (PPA) may be more useful for individuals who are not be able to achieve placement cues (Van Riper, 1978). In 1958, Van Riper stated:

"Every available device should be used to make the student understand clearly the positions of the tongue, jaw, and lips to be assumed."

Placement cues are based on the more traditional models of therapy, and rely on the concept that an individual can copy the motor plan suggested by the therapist, such as “place your tongue tip to the spot.” Therapists, however, often struggle with a population of individuals who do not respond well to “look at me and say what I say,” and those who require a tactile-kinesthetic approach to treatment (Bahr & Rosenfeld-Johnson, 2010). Individuals with dysarthria, dyspraxia and/or myofunctional disorders may make slow progress, or no progress at all, without the assistance of tactile cues. Even though therapists have heard the debate on oral motor therapy (Bowen, 2006; Lof, 2006; Lof, 2007; Lof, 2009), clinicians are still widely using the techniques because they yield positive treatment outcomes (Bahr, 2008).

Clinicians, who represent the Board of Directors for the Oral Motor Institute, have struggled with distinguishing “oral motor therapy” from the form of “Non Speech Oral Motor Exercises” (NSOME) presented by Gregory Lof (Lof, 2008). The term “Oral Placement Disorder” (OPD) was coined by Diane Bahr and Sara Rosenfeld-Johnson in 2010 (Bahr & Rosenfeld-Johnson, 2010). Children with OPD cannot imitate targeted speech sounds using auditory and visual stimuli (i.e., “Look, listen, and say what I say”). They also cannot follow specific instructions to produce targeted speech sounds (e.g., “Put your lips together and say m”). Although the term OPD is new, the concepts surrounding the term have been discussed by a number of authors and clinicians (Bahr, 2010; Hodge, 2012; Marshalla, 2007).

There has been question, and ongoing confusion, as to what is a NSOME, versus what is an oral placement technique (OPT) (Bahr & Rosenfeld-Johnson, 2010). Oral Placement Therapy (OPT) is a tactile teaching technique used for children and adults with Oral Placement Disorders (e.g., dysarthria), who cannot learn standard speech sound production using auditory and visual teaching methods alone. OPT facilitates the pre-requisite skills in muscle control to develop dissociation and grading in the muscles of the abdomen, velum, jaw, lips and tongue for clients who cannot approximate the standard speech sounds using the instructions. If the client can produce standard speech using adequate placement and duration using only auditory and visual cueing, OPT would not be included in that client’s program plan.

Gregory Lof’s research has even stated that the methods used in Van Riper’s Phonetic Placement Approach are not in fact considered NSOME (Lof, 2009). This is why it is important to explore current clinical techniques to determine what activities are considered unrelated to speech production, as opposed to those activities that in fact are an extension of Phonetic Placement Therapy (Marshalla, 2007).

OPT IS A MODERN EXTENSION OF PHONETIC PLACEMENT THERAPY

(Van Riper, 1954) and The Feedback Model (Mysak, 1971).

It is based on a very common sequence (Bahr, 2001; Green, Moore & Reilly, 2000; Marshalla, 2007; Young and Hawk, 1955):

1. Facilitate speech movement with the assistance of a therapy tool (ex. horn, tongue depressor) or a tactile-kinesthetic facilitation technique (ex. PROMPT facial cue); use every available device (Marshalla, 2012);

2. Facilitate speech movement without the therapy tool and/or tactile-kinesthetic technique (cue fading);

3. Immediately transition movement into speech with and without therapy tools and/or tactile kinesthetic techniques.

TalkTools | Pam Marshalla

PHONETIC PLACEMENT THERAPY TOOLS

TalkTools | Van Riper tools

MODERN ORAL PLACEMENT THERAPY TOOLS

TalkTools | Van Riper new tools

REFERENCES

Bahr, D. (2008). The oral motor debate: Where do we go from here? Poster session presented at the annual meeting of the American Speech-Language-Hearing Association, Chicago, IL. (Full handout at http://convention.asha.org/handouts.cfm)

Bahr, D. (2001). Oral motor assessment and treatment: Ages and stages. Boston: Allyn and Bacon.

Bahr, D. & Rosenfeld-Johnson, S. (2010). Treatment of Children With Speech Oral Placement Disorders (OPDs): A Paradigm Emerges. Communication Disorders Quarterly, XX(X), 108.

Bowen, C. (2005). What is the evidence for oral motor therapy? ACQuiring Knowledge in Speech, Language and Hearing, Speech Pathology Australia, 7, 3, 144-147.

Green, R., Moore, C. A., & Reilly, K. J. (2000). The sequential development of jaw and lip control for speech. Journal of Speech, Language and Hearing Research, 45, 66-79.

Hodge, M. M. (2002). Non-speech oral motor treatment approaches for dysarthria: Perspectives on a controversial clinical practices. Perspectives in Neurophysiology and Neurogenic Speech Disorders, 12 (4), 22-28.

Klein, E. S. (1996). Phonological/traditional approaches to articulation therapy. Language, Speech, and Hearing Services in Schools, Vol. 27, 314-323.

Lof, G. L. (2007). Reasons why non-speech oral motor exercises should not be used for speech sound disorders. Presentation at the ASHA Annual Convention, Boston, MA, Nov. 17.

Lof, G. L. (2009). Nonspeech oral motor exercises: an update on the controversy. Presentation at ASHA Annual Convention, New Orleans, LA.

Lof, G. L. (2006). Logic, theory and evidence against the use of non-speech oral-motor exercises to change speech sound productions. Invited presentation at the ASHA Annual Convention, Miami, FL, Nov. 17.

Lof, G. L. & Watson, M. (2005). Survey of universities’ teaching: oral motor exercises and other procedures. Poster presented at the annual meeting of the American Speech-Language-Hearing Association, San Diego, CA.

Lof, G. L. (2004). Ask the Expert: A response by Gregory L. Lof, PhD., CCC-SLP. The Apraxia-Kids Monthly, 5 (1).

Lof, G. L. & Watson, M. (2004). Speech-language pathologist’s use of non-speech oral-motor drills: National survey results. Poster presented at the annual meeting of the American Speech-Language-Hearing Association, Philadelphia, PA.

Lof, G. L. (2003). Oral motor exercises and treatment outcomes. Perspectives on Language Learning and Education, 10 (1), 7-11.

Marshalla, P. (2007). Oral motor techniques are not new. Oral Motor Institute, 1(1). Available at www.oralmotorinstitute.org.

Marshalla, P. (2012). Horns, whistles, bite blocks, and straws: A review of tools/objects used in articulation therapy by Van Riper and other traditional therapists. Oral Motor Institute, 4 (2). Available at www.oralmotorinstitute.org.

Mysak, E. (1971). Speech pathology and feedback therapy. Charles C. Thompson Publisher.

Van Riper, C. (1958, 1954, 1947). Speech Correction: Principles and Methods. Englewood Cliffs: Prentice-Hall.

Young, E. H. & Hawk, S. S. (1955). Moto-kinesthetic speech training. Stanford, CA: Stanford University Press.

Read more →

Effects of Limited or Excessive Jaw Mobility During Conversational Speech

Posted by Deborah Grauzam on

by Sara Rosenfeld-Johnson

This presentation was made at the 2015 annual ASHA Convention, Session #1080.

Abstract:

Practicing Speech-Language Pathologists report that many clients demonstrate limited or excessive up-and-down jaw movements during communication as compared to their typically developing peers.  The results of this retrospective study suggest that atypical jaw skills are related to deficits in speech clarity in clients diagnosed with multiple articulation disorder and dysarthria.

Summary:

Practicing Speech-Language Pathologists report that many clients, with diagnosed multiple articulation disorders, demonstrate limited or excessive up-and-down jaw movements during communication as compared to their typically developing peers.  The focus of this retrospective study was to determine if children and adults, diagnosed with multiple articulation disorders, were using the jaw heights needed to allow the tongue and lips to move independently for consonant and vowel productions on the conversational level. “Individual differences in jaw movement are real and often large; and the jaw is, in a real sense a primary articulator, controlling tongue height for an open vowel (Gay, 1974).   Video clips of clients’ jaw mobility during conversational speech, before and after bite block invention, will be shown throughout this presentation.

These same clients were often able to produce the targeted speech sound(s) on the word level in a standardized articulation test but could not produce these same phonemes consistently on the conversational level.  The sentence, “As the rate and complexity of the statement increases, the intelligibility decreases,” is  found in many SLP’s reports to describe this breakdown in speech clarity.

More than forty years ago Edward Mysak suggested that if articulatory efforts are disrupted by excessive orofacial activities, as observed in many children with cerebral palsy, therapeutic techniques designed to restrain these compounding events must be administered to facilitate speech improvement (Mysak 1968).  Ten years later James Dworkin proposed a causal relationship between the articulatory imprecision exhibited by certain school-age children and their co-occuring interruptive, hyperactive or hypoactive mandibular movement patterns” (Dworkin 1978).  Clinical focus was then shifted to a treatment method that could measure the degree of jaw activity.  Acrylic bite blocks of varying heights were positioned between the upper and lower central incisor teeth. The children were required to bite down gently on a given block, so as to stabilize the mandible.  Substantial improvements in speech proficiency and intelligibility were obtained in all of the children studied in a relatively short period of time (Dworkin 1978). Kent and Lybolt (1982), Rosenbek and LaPointe (1985), Netsell (1985), and Dworkin (1991) all discussed the potential diagnostic and therapeutic value of bite block use in the differential diagnosis and treatment of dysarthric patients.

Other studies support the idea that SLPs need to take a closer look at how jaw grading is related to speech production.  A 2000 study reported, “precise control of jaw movements precedes lip-control, control over jaw and lip coupling, and independence of upper- and lower-lip movement” and “the present results might be taken to suggest that limited mandibular control in early speech is a negative prognostic factor for later speech motor delays” (Green, 2000).  Research into myofunctional disorders identified the relationship between the tongue and jaw dissociation for speech (Meyer, 2000).

In 2003, the following comments were made in a response to the Green, Moore, and Reilly article (Green, 2002) in reference “to the select populations of children and adults with developmental or neurogenic articulation disorders who exhibit mandibular dyscontrol. On the basis of our present work with such patients and a reinforcing clinical literature database, we suggest that the mandible may play a leading role not only in normal articulatory development but also in the origin and persistence of certain abnormal speech behaviors (Dworkin, 2003).

In our present study the charts of several different clinical populations were examined.  Subjects were chosen based upon the examiner’s comment that limited or excessive mandibular activity was observed during conversational speech.  A video-based movement tracking system had been used to chart the jaw range of motion in connected speech for each of the subjects. In the initial evaluation both the Goldman-Fristoe Test of Articulation (G-FTA-2) and the DCOMT (Dworkin-Culatta Oral Mechanism Examination and Treatment System) had been administered.  Based on the results of these inventories, all subjects had been diagnosed with a multiple articulation disorder and dysarthria. Client’s with the diagnosis of motor speech disorders such as Childhood Apraxia of Speech (CAS) or Acquired Apraxia of Speech (AOS) were not included in this study.

Bite blocks representing the following jaw heights were used to assess skills at the high jaw placement (m, b, p, f, v, n, s, z, ∫, t∫, r, vocalic r, I, I, Ʋ, u – teeth almost touching), medium jaw placement (θ, ð, l, t, d,Λ, ɛ, ə, ɔ - teeth slightly more open) and low jaw placement (g, k, h,ɑ, æ - teeth even slightly more open) (Marshalla, 1982).

Prior to data collection, these same bite blocks were used to assess the jaw skills of twenty-five randomly selected children and adults between the ages of 2.5 and 50 years whose speech clarity was considered to be within normal limits as reported by an independent judge. The task was to use the back molars to bite-and-hold the jaw still for fifteen (15) seconds, at each bite block height, while an isometric pull was introduced.  Each of these twenty-five individuals was able to perform the bite block task without error.  The SRJ Therapies client charts, spanning a period of 12 years, were then examined.  The following clients qualified for the study: 1) Down syndrome: 230, 2) Cerebral Palsy: 24, 3) Benign Hypotonia: 180, 4) Other syndromes characterized by hypotonia: 33, and 5) Clients with no medical diagnosis who had been enrolled in speech therapy for a minimum of four years  and who had not demonstrated significant improvement: 42.  The clients ranged in age from 2.5 years to 47 years.

The results of this retrospective study are remarkable in that only 8% of the 509  client-subjects were able to perform the bite block task without error; 92%  could not complete the task. These results suggest that jaw skills are related to deficits in speech clarity in clients with the diagnosis of a muscle-based multiple articulation disorder and dysarthria.  Because this was a retrospective study the limitations are clear. The next step would be large sample, double-blind studies that would definitively address the use of bite blocks for diagnosis and treatment of clients with muscle-based speech clarity disorders.

Learner Outcomes:

  1. Participants will be able to identify client’s with atypical jaw mobility during conversational speech.
  1. Participants will understand the possible relationship between atypical jaw mobility and dysarthria
  1. Participants will be able to use bite blocks to assess jaw skills in clients with the diagnosis of dysarthria

References:

Dworkin, J. P. (1978). A therapeutic technique for the improvement of lingua-alveolar valving abilities. Journal of Language, Speech, and Hearing Services in Schools, 9, 162-175.

Dworkin, J. P. (1991). Motor speech disorders: A treatment guide- book. St. Louis: Mosby.

Dworkin, J. P. (1996). Bite block therapy for oromandibular dystonia. Journal of Medical Speech-Language Pathology, 4, 47-56.

Dworkin, J.P, Meleca, R.J., Stachler R.J. (2003) More on the Role of the Mandible in Speech Production: Clinical Correlates for Green, Moore, and Reilly’s (2002) Findings. Journal of Speech, Language, and Hearing Research, 46 (pp. 1020-1021).

Gay, T. J., Ushijima, T., Hirose, H., & Cooper, F. S. (1974). Effect of speaking rate on labial consonant-vowel articulation. Journal of Phonetics, 2, 47-63.

Green, J. R., Moore, C. A., Higashikawa, M., & Steeve, R. W. (2000). The physiologic development of speech motor control: Lip and jaw coordination. Journal of Speech, Language, and Hearing Research, 43, 239-255.

Green, J. R., Moore, C. A., & Reilly, K. J. (2002). The sequential development of jaw and lip control for speech. Journal of Speech, Language, and Hearing Research, 45, 66-79.

Kent, R., & Lybolt, J. (1982). Techniques of therapy based on motor learning theory. In W. H. Perkins (Ed.), Current therapy of communication disorders: General principles of therapy (pp. 13-25). New York: Thieme-Stratton.

Marshalla, (Rosenwinkel), P. (1982) Tactile-proprioceltive stimulation techniques in articulation therapy. Seminar handbook. Champaign: Innovative concepts in Speech and Language.

Meyer, P.G. (2000). Tongue lip and jaw differentiation and its relationship to orofacial myofunctional treatment. Int J Orofacial Myology, 26, 44-52

Mysak, E. D. (1968). Neuroevolutional approach to cerebral palsy and speech. New York: Teachers College Press.

Netsell, R. (1985). Construction and use of a bite-block for the evaluation and treatment of speech disorders. Journal of Speech and Hearing Disorders, 50, 103-106.

Rosenbek, J. C., & LaPointe, L. L. (1985). The dysarthrias: Description, diagnosis, and treatment. In D. F. Johns (Ed.), Clinical management of neurogenic communicative disorders (pp. 97-152). Boston: College Hill Press.

Read more →

Horns, Whistles, Bite Blocks and Straws by Pam Marshalla

Posted by Deborah Grauzam on

This excellent article by Pam Marshalla, MA, CCC-SLP is posted on the Oral Motor Institute site and discusses how some tools and methods have been categorized as "nonspeach oral motor exercises" (NSOME) but these same tools and methods were used by Van Riper and other pioneers of articulation therapy.

Click here to Read
